Distinguished by an extremely compact body, CAPITAL 100 MC DW complies with the most actual architectural lighting specifications. Masterfully responding to aesthetic appeal and chromatic adaptability criteria, CAPITAL 100 MC DW is fitted with 8 premium quality high brightness multichip power LEDs with an adjustable colour temperature range between 3000K and 6500K, which enhance seamless light distribution and smooth colour temperature transition. This highly flexible and versatile surface mount floodlight, coming with an expansive selection of optical configurations and body finishes, is fully suitable for a comprehensive variety of installations where a reduced mounting space leaves no wide choice to the most innovative lighting designers. The pure white light spectrum intensity management creates a stunning visual rendering of warm tones, natural hues and cool shades altogether, thus offering an unmatched control over the creation of a vast array of the white light chromatic scale for an even broader assortment of application purposes. The Polar Edition is equipped with an integrated de-icing system with electrically heated glass, which assures a comfortable functioning even in the utmost severe cold weather conditions.
Colour configuration
High brightness Dynamic White multichip LEDs with an adjustable colour temperature range between 3000K and 6500K
Optical configuration
7° SP (Spot) 10° NA (Narrow) 23° ME (Medium) 35° WI (Wide)
Max. Delivered lumen output
5440 lm
Max. lumen/Watt
74 lm/W
Input voltage
220-240VAC / 50-60Hz
Power consumption
0.33A@230V / 74W max.
Ingress protection rating
IP67
Impact resistance rating
IK09
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Optional feature
The fixture is also available in Class II, on request
Polar Edition
Available on request.
Warranty
5-year warranty
Accessories
Optional optical distribution and mounting accessories available for the utmost design flexibility
