Capital 100 White Light DMX-DALI

Capital 100 White Light DMX-DALI

AL5005
AL5007 Polar Edition

  • Compact surface mount floodlight
  • 282x82x282 mm / 11.1x3.2x11.1"
  • Comprehensive selection of optical configurations
  • Polar Edition version available
  • High brightness natural or warm white power LEDs

View finishes: Black RAL 9005
  • Black RAL 9005
  • Anthracite RAL 7016
  • Grey RAL 9006
  • White RAL 9003
  • Custom RAL available on request
View LED colour configuration: Natural White 4000K
  • Natural White 4000K
  • Warm White 3000K
  • 27 Warm White 2700K
Contact us  Save product
TUNABLE & SOLID WHITE LIGHT
print

Capital 100 White Light DMX-DALI

General Features

Hosting 32 premium quality high brightness power LEDs, CAPITAL 100 W delivers supremely remarkable performances from a strikingly compact body. Perfectly matching the demanding needs of the most imaginative architectural lighting specifications, this highly flexible and versatile surface mount floodlight, coming with a vast selection of optical configurations and body finishes, is fully suitable for a comprehensive variety of installations where a reduced mounting space leaves no wide choice to the most innovative lighting designers. The natural or warm white LEDs set-ups available provide an unprecedented astonishing white light output quality allowing a broad range of application purposes. The Polar Edition is equipped with an integrated de-icing system with electrically heated glass, which assures a comfortable functioning even in the utmost severe cold weather conditions.
Video
Colour configuration
High brightness 4000K Natural White, 3000K and 2700K Warm White or, on request, monochrome power LEDs
Optical configuration
12° SP (Spot)
15° NA (Narrow)
25° ME (Medium)
47° WI (Wide)
61° EW (Extra wide)
14°x39° EL (Elliptical)
22°x37° WL (Elliptical wide)
19° (5° incline)x37° WW (Wall wash)
Max. Delivered lumen output
7319 lm
Max. lumen/Watt
106 lm/W
Input voltage
220-240VAC / 50-60Hz
Power consumption
0.31A@230V / 69W
Ingress protection rating
IP67
Impact resistance rating
IK09
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Optional feature
The fixture is also available in Class II, on request
Polar Edition
Available on request.
Warranty
5-year warranty
Accessories
Optional optical distribution and mounting accessories available for the utmost design flexibility

Light Beam Effects

  • Spot
  • Narrow
  • Medium
  • Wide
  • Extra Wide
  • Elliptical
  • Elliptical wide
  • Wall wash


Overview

  • IP67
  • IK09
  • DMX
  • RDM
  • DALI
  • Wireless
  • I
  • Meets CE safety standards, Rohs compliant

Optional Features

  • Corrosion resistant coating for product installation in coastal environment available on request
  • Optional Polar
  • Integrated wireless control system available on request.
  • ETL Listed
  • Class II
