Capital 200 MC Dynamic White

Capital 200 MC Dynamic White

AL5011
AL5013 Polar Edition

  • Ideal for spot lighting and wall washing effects
  • 460x90x276 mm / 18.1x3.5x10.9"
  • Premium quality high brightness dynamic white multichip power LEDs
  • Seamless light distribution and smooth colour temperature transition
  • Polar Editon version available

View finishes: Black RAL 9005
  • Black RAL 9005
  • Anthracite RAL 7016
  • Grey RAL 9006
  • White RAL 9003
  • Custom RAL available on request
Contact us  Save product
TUNABLE & SOLID WHITE LIGHT
print

General Features

Masterfully responding to aesthetic appeal and chromatic adaptability criteria, CAPITAL 200 MC DW delivers outstanding performances from a compact body. This highly flexible and versatile surface mount floodlight, coming with a vast selection of optical configurations and body finishes, is fully suitable for a comprehensive variety of installations. The pure white light spectrum intensity management creates a stunning visual rendering of warm tones, natural hues and cool shades altogether, thus offering an unmatched control over the creation of a vast range of the white light chromatic scale. The Polar Edition is equipped with an integrated de-icing system with electrically heated glass, which assures a comfortable functioning even in the utmost severe cold weather conditions.
Colour configuration
High brightness Dynamic White multichip LEDs  with an adjustable colour temperature range between 3000K and 6500K
Optical configuration
7° SP (Spot)
10° NA (Narrow)
23° ME (Medium)
35° WI (Wide)
Max. Delivered lumen output
4524 lm (SP DW configuration)
Input voltage
100-277VAC / 50-60 Hz
Power consumption
0.73A@230V / 159W max.
Ingress protection rating
IP67
Impact resistance rating
IK09
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Optional feature
The fixture is also available in Class II, on request
Polar Edition
Available on request.
Warranty
5-year warranty
Accessories
Optional optical distribution and mounting accessories available for the utmost design flexibility

Light Beam Effects

  • Spot
  • Narrow
  • Medium
  • Wide


Overview

  • IP67
  • IK09
  • DMX
  • RDM
  • I
  • Meets CE safety standards, Rohs compliant

Optional Features

  • Corrosion resistant coating for product installation in coastal environment available on request
  • Optional Polar
  • Integrated wireless control system available on request.
  • ETL Listed
  • Class II
