Capital 200 White Light

AL5010
AL5012 Polar Edition

  • Surface mount floodlight
  • 460x90x276 mm / 18.1x3.5x10.9"
  • Comprehensive selection of optical configurations
  • Polar Edition version available
  • High brightness cold, natural or warm white power LEDs

View finishes: Black RAL 9005
  • Black RAL 9005
  • Anthracite RAL 7016
  • Grey RAL 9006
  • White RAL 9003
  • Custom RAL available on request
View LED colour configuration: Cold White 6500K
  • Cold White 6500K
  • Natural White 4000K
  • Warm White 3000K
Contact us  Save product
TUNABLE & SOLID WHITE LIGHT
print

General Features

Smoothly blending in every architectural background through its undoubtedly modern and sleek design, CAPITAL 200 W, hosting 64 premium class high brightness power LEDs, delivers outstanding performances from a compact body. Coming with a vast selection of high build optics groups for the maximum optical efficiency, this surface mount floodlight assures balanced projection and photometric flexibility matching the selective demands of the most sophisticated architectural lighting prerequisites. A comprehensive choice of body finishes further enhances this light fitting versatility. The cool, natural or warm white LEDs set-ups available provide an unprecedented astonishing white light output quality allowing a broad range of application purposes. The Polar Edition is equipped with an integrated de-icing system with electrically heated glass, which assures a comfortable functioning even in the utmost severe cold weather conditions.
Colour configuration
High brightness Cold White, Natural White, Warm White or, on request, monochrome power LEDs
Optical configuration
12° SP (Spot)
15° NA (Narrow)
25° ME (Medium)
47° WI (Wide)
61° EW (Extra wide)
14°X39° EL (Elliptical)
22°x37° WL (Elliptical wide)
19° (5° incline)x37° WW (Wall wash)
Max. Delivered lumen output
16275 lm (SP CW configuration)
Input voltage
100-277VAC / 50-60 Hz
Power consumption
0.68A@230V / 148W max.
Ingress protection rating
IP67
Impact resistance rating
IK09
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Optional feature
The fixture is also available in Class II, on request
Polar Edition
Available on request.
Warranty
5-year warranty
Accessories
Optional optical distribution and mounting accessories available for the utmost design flexibility

Light Beam Effects

  • Spot
  • Narrow
  • Medium
  • Wide
  • Extra Wide
  • Elliptical
  • Elliptical wide
  • Wall wash


Overview

  • IP67
  • IK09
  • DMX
  • RDM
  • DALI
  • I
  • Meets CE safety standards, Rohs compliant

Optional Features

  • Corrosion resistant coating for product installation in coastal environment available on request
  • Optional Polar
  • Integrated wireless control system available on request.
  • ETL Listed
  • Class II

Downloads
