Capital 600 Dynamic White

AL5022 Polar Edition

  • Double cluster surface mount powerful floodlight
  • 756x150x517 mm / 29.8x5.9x20.4"
  • Full independent control of each LED bank
  • Creation of matching or divergent dynamic effects on large-scale façades
  • High brightness tunable white power LEDs

View finishes: Black RAL 9005
  • Black RAL 9005
  • Anthracite RAL 7016
  • Grey RAL 9006
  • White RAL 9003
  • Custom RAL available on request
Contact us  Save product

General Features

Coupling a minimal, neat design with brilliant performances, CAPITAL 600 DW, hosting 192 premium quality high brightness power LEDs, is available with a vast selection of combinable optics for the maximum lighting design flexibility. A comprehensive choice of body finishes further enhances this light fitting versatility. Featuring full independent control of each LED bank, this double cluster luminaire allows absolute freedom to create impressive matching or divergent dynamic effects on large-scale façades, high-rise buildings, remote spots and many other architectural structures with a surprising luminous output. With an adjustable colour temperature between 2700K and 6500K, the pure white light spectrum intensity management creates a stunning visual rendering of warm tones, natural hues and cool shades altogether, thus offering an unmatched control over the creation of a vast range of the white light chromatic scale for an even broader range of application purposes. The Polar Edition is equipped with an integrated de-icing system with electrically heated glass, which assures a comfortable functioning even in the utmost severe cold weather conditions.
Colour configuration
High brightness Dynamic White LEDs  with an adjustable colour temperature range between 2700K and 6500K
Optical configuration
12° SP (Spot)
15° NA (Narrow)
25° ME (Medium)
47° WI (Wide)
61° EW (Extra wide)
14°X39° EL (Elliptical)
23°x37° WL (Elliptical wide)
19° (5° incline)x37° WW (Wall wash)
Max. Delivered lumen output
55860 lm
Max. lumen/Watt
98 lm/W
Input voltage
100-277VAC / 50-60 Hz
Power consumption
2.58A@230V / 570W max. total (1.29A@230V / 285W each bank)
Ingress protection rating
Impact resistance rating
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Optional feature
The fixture is also available in Class II, on request
Polar Edition
Available on request.
5-year warranty
Optional optical distribution and mounting accessories available for the utmost design flexibility


  • IP67
  • IK09
  • DMX
  • RDM
  • I
  • Meets CE safety standards, Rohs compliant
  • Made in Italy

Optional Features

  • Corrosion resistant coating for product installation in coastal environment available on request
  • Optional Polar
  • Integrated wireless control system available on request.
  • ETL Listed
  • Class II
