Capital 600 RGBW

AL5022 Polar Edition

  • Max. delivered lm output: 32402 lm / 63 lm/W
  • Size: (HxWxD) 756x517x150 mm / 29.7x20.4x5.9”
  • Control system: DMX-RDM, DALI DT8, DALI, remote wireless data
  • Double cluster floodlight with full independent control of each LED bank

View finishes: Black RAL 9005
  • Black RAL 9005
  • Anthracite RAL 7016
  • Grey RAL 9006
  • White RAL 9003
  • Custom RAL available on request
View LED colour configuration: RGB+W 4000K
  • RGB+W 4000K
  • RGB+W 3000K
Contact us  Save product

General Features

Coupling a minimal, neat design with brilliant performances, CAPITAL 600 RGBW, hosting 192 premium quality high brightness power LEDs, is available with a vast selection of combinable optics for the maximum lighting design flexibility. A comprehensive choice of body finishes further enhances this light fitting versatility. Featuring full independent control of each LED bank, this double cluster luminaire allows absolute freedom to create impressive matching or divergent dynamic effects on large-scale façades, high-rise buildings, remote spots and many other architectural structures with a surprising luminous output. The combination of prime class RGBW LEDs, featuring either 4000K natural white or 3000K warm white, delivers the widest range of warm white shades and pastel tones assortment. The Polar Edition is equipped with an integrated de-icing system with electrically heated glass, which assures a comfortable functioning even in the utmost severe cold weather conditions.
Colour configuration
High brightness RGB+W 4000K or 3000K LEDs
Optical configuration
8° SP (Spot)
12° NA (Narrow)
23° ME (Medium)
43° WI (Wide)
68° EW (Extra wide)
11°X41° EL (Elliptical)
22°x39° WL (Elliptical wide)
14° (5° incline)x37° WW (Wall wash)
Max. Delivered lumen output
32402 lm
Max. lumen/Watt
63 lm/W
Input voltage
100-277VAC / 50-60 Hz
Power consumption
2.32A@230V / 512W max. total (1.16A@230V / 256W each bank)
Ingress protection rating
Impact resistance rating
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Optional feature
The fixture is also available in Class II, on request
Polar Edition
Available on request.
5-year warranty
Optional optical distribution and mounting accessories available for the utmost design flexibility


  • IP67
  • IK09
  • DMX
  • RDM
  • I
  • Meets CE safety standards, Rohs compliant
  • Made in Italy

Optional Features

  • Corrosion resistant coating for product installation in coastal environment available on request
  • Optional Polar
  • Integrated wireless control system available on request.
  • ETL Listed
  • Class II
