Dune MC MK3 Dynamic White

AL5004

  • Premium class dynamic white LEDs
  • Ø 345 mm 306 x 365 mm / Ø 13.6" 12x14.4"
  • 9° beam angle orientation adjustment
  • 2000 Kg deadweight load capacity
  • Polar Edition available

Contact us  Save product
TUNABLE & SOLID WHITE LIGHT
print

General Features

Featuring a smart beam angle orientation adjustment, DUNE MC MK3 DW is a highly performing ip68 rated LED up-lighter ideal for spot lighting, wall grazing and wall washing effects in exterior recessed applications. It is based on an efficient combination of powerful tunable white multichip LEDs, with an adjustable colour temperature range between 3000K and 6500K, which enhances seamless light distribution and smooth transition. Its AISI 316L stainless steel body features a 2000 Kg deadweight load capacity, which makes it suitable for in-ground applications even in vehicular areas. The Polar Edition features an integrated de-icing system with electrically heated glass, which assures a comfortable functioning even in the utmost severe cold weather conditions.
Colour configuration
High brightness Dynamic White multichip LEDs  with an adjustable colour temperature range between 3000K and 6500K
Optical configuration
7° SP (Spot)
10° NA (Narrow)
23° ME (Medium)
35° WI (Wide)
Input voltage
100-240VAC / 50-60 Hz
Power consumption
0.4A@230VAC / 45W
Ingress protection rating
IP68 (-1.5m)
Impact resistance rating
IK10
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Warranty
2-year warranty
Accessories
Unless an RDM compatible control is used, this fixture must always be purchased with AL1321 Infrared Remote Control. More units can be controlled with one AL1321. The formwork code AL8349 must be purchased separately.

Light Beam Effects

  • Spot
  • Narrow
  • Medium
  • Wide


Overview

  • IP68 (-1.5m)
  • IK10
  • DMX
  • RDM
  • I
  • Meets CE safety standards, Rohs compliant

Optional Features

  • Anti-slip treatment, for a safe and comfortable use in pedestrian areas, available on request
  • Polar
  • ETL pending
