Dune MC MK3 Dynamic White


  • Max. delivered lm output: 2941 lm /74 lm/W
  • Size: (WxD) ø 306x365 mm / ø 12x14.4”
  • Control system: DMX-RDM, remote wireless data
  • Drive-over multichip LED uplighter with smart beam angle orientation adjustment
  • Please note that the formwork must be purchased separately

Contact us  Save product

General Features

Featuring a smart beam angle orientation adjustment, DUNE MC MK3 DW is a highly performing ip68 rated LED up-lighter ideal for spot lighting, wall grazing and wall washing effects in exterior recessed applications. It is based on an efficient combination of powerful tunable white multichip LEDs, with an adjustable colour temperature range between 3000K and 6500K, which enhances seamless light distribution and smooth transition. Its AISI 316L stainless steel body features a 2000 Kg deadweight load capacity, which makes it suitable for in-ground applications even in vehicular areas. The Polar Edition features an integrated de-icing system with electrically heated glass, which assures a comfortable functioning even in the utmost severe cold weather conditions.
Colour configuration
High brightness Dynamic White multichip LEDs  with an adjustable colour temperature range between 3000K and 6500K
Optical configuration
8° SP (Spot)
10° NA (Narrow)
24° ME (Medium)
37° WI (Wide)
Max. Delivered lumen output
2941 lm
Max. lumen/Watt
74 lm/W
Input voltage
100-240VAC / 50-60 Hz
Power consumption
0.2A@230V / 40W max.
Ingress protection rating
IP68 (-1.5 m). NOT SUITABLE FOR UNDERWATER USE. The fixture is resistant to submersion up to a maximum depth of 1.5m underwater for up to thirty minutes.
Impact resistance rating
External operating limits
-40°C to 50°C / (-40°F to 122°F)
2-year warranty
Unless an RDM compatible control is used, this fixture must always be purchased with AL1321 Infrared Remote Control. More units can be controlled with one AL1321. The formwork code AL8349 must be purchased separately.

Light Beam Effects

  • Spot
  • Narrow
  • Medium
  • Wide


  • IP68 (-1.5m)
  • IK10
  • DMX
  • RDM
  • I
  • Drive-over
  • Meets CE safety standards, Rohs compliant
  • Made in Italy

Optional Features

  • Anti-slip treatment, for a safe and comfortable use in pedestrian areas, available on request
  • Polar
  • ETL pending
