With its waterproof IP68 protection rating, AISI 316L stainless steel body, and 9° beam angle tilt orientation adjustment, DUNE MK3 DW is a highly performing LED recessed uplighter specifically designed for exterior in-ground applications. Delivering spot lighting as well as wall grazing effects, DUNE MK3 DW is based on a combination of premium class tunable white LEDs, with an adjustable colour temperature range between 2700K and 6500K. Narrow aperture spot lenses and elliptical wide distribution are part of the optics groups available. The 2000 Kg deadweight load capacity makes it suitable for in-ground applications even in vehicular areas. The Polar Edition features an integrated de-icing system with electrically heated glass, which assures a comfortable functioning even in the utmost severe cold weather conditions.
Colour configuration
High brightness Dynamic White LEDs with an adjustable colour temperature range between 2700K and 6500K
Optical configuration
12° Spot (SP) 15° NA (Narrow) 25° ME (Medium) 47° WI (Wide) 61° EW (Extra wide) 14°X39° EL (Elliptical) 23°x37° WL (Elliptical wide)
Max. lumen/Watt
109 lm/W
Max. nominal lumen output
2954 lm
Input voltage
100-240VAC / 50-60 Hz
Power consumption
0.16A@230VAC / 27W
Ingress protection rating
IP68 (-1.5 m). NOT SUITABLE FOR UNDERWATER USE. The fixture is resistant to submersion up to a maximum depth of 1.5m underwater for up to thirty minutes.
Impact resistance rating
IK10
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Warranty
2-year warranty
Accessories
Unless an RDM compatible control is used, DUNE MK3 DW must always be purchased with AL1321 Infrared Remote Control. More units can be controlled with one AL1321. Beehive antiglare filter available. The formwork code AL8349 must be purchased separately.
