GEA RGBW

AL8410

  • Max. delivered lm output: 2059 lm / 39 lm/W
  • Size: (LxWxD) 410x345x153 mm / 16.14x13.58x6.02"
  • Control system: DMX-RDM
  • High-performance in-ground uplighter featuring a combination of three different optics to create an even wall wash effect on both close-up and distant installations
  • The formwork must be purchased separately

View LED colour configuration: RGB+W 4000K
  • RGB+W 4000K
  • RGB+W 3000K
Contact us  Save product
COLOUR CHANGING
print

General Features

Conceived and engineered according to the specifications of the renowned lighting designer Francesca Storaro, GEA RGBW is an innovative in-ground luminaire that stands out for its unique shape, function, and performance. An unprecedented optical configuration, featuring three independently manageable LED rows fitted with different bespoke optics, delivers an even wall wash effect for both close-up and distant installations, with a well-defined light projection reaching heights of up to 18 meters. An elegant frame allows for seamless, discreet integration into pavements in historic or modern urban environments. The combination of high-quality RGBW LEDs, available with either 4000K natural white or 3000K warm white, provides the broadest range of warm white shades and pastel tones. Where required, an optional built-in anti-glare filter prevents glaring effects.
Colour configuration
High brightness RGB+W 4000K or 3000K LEDs
Optical configuration
Unique optical configuration featuring 3 independently manageable LEDs rows fitted with different bespoke optics.
Max. Delivered lumen output
2059 lm
Max. lumen/Watt
39lm/W
Input voltage
220-240VAC / 50-60Hz
Power consumption
0.24A@230V / 53W
Ingress protection rating
IP67
Impact resistance rating
IK10
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Optional feature
The fixture is also available in Class II, on request
Warranty
2-year warranty
Accessories
Unless an RDM compatible control is used, this uplighter must always be purchased with AL1321 Infrared Remote Control. More units can be controlled with one AL1321. Antiglare filter available on request. The formwork code AL8455 must be purchased separately.

Light Beam Effects

  • Dynamic Wall Wash


Overview

  • IP67
  • IK10
  • DMX
  • RDM
  • I
  • Meets CE safety standards, Rohs compliant
  • Made in Italy

Optional Features

  • Anti-slip treatment, for a safe and comfortable use in pedestrian areas, available on request
  • ETL certified version available on request
  • Class II
