Goboled 500

AL5179

  • Outdoor rated image projector
  • 332x536x454mm / 13x21.1x17.9"
  • Bright and accurate rendition of graphic designs, logos and animations
  • Multiple images projection effects
  • Extreme reliability and totally noiseless operation

View finishes: Black RAL 9005
  • Black RAL 9005
  • Anthracite RAL 7016
  • Grey RAL 9006
  • White RAL 9003
  • Custom RAL available on request
Contact us  Save product
COLOUR CHANGINGTUNABLE & SOLID WHITE LIGHT
print

General Features

Packed with multiple effects, patterns and a motorized zoom, GOBOLED 500 offers broad creative design integration for permanent exterior installations. Fitted with one high power LED, this cutting edge image projector delivers a bright and accurate rendition of graphic designs, logos and animations in outdoor and indoor locations.
Colour configuration
One high brightness 8000K power LED
Optical configuration
7°-37° motorized zoom
Max. Delivered lumen output
9800 lm (min. zoom) / 13834 lm (max. zoom)
Electronic blackout
Motorized focus
7 interchangeable rotating gobos wheel (ø 27/22 mm);
4 fixed gobos plus animation effect wheel
8 colours + white wheel
2 prisms with variable rotation (8 facets and 3D effect)
Pulse effect
Input voltage
100-240VAC / 50-60 Hz
Power consumption
2.51A@230VAC / 560W (heater on), 1.98A@230VAC / 425W (heater off)
Ingress protection rating
IP66
Impact resistance rating
IK07
External operating limits
-30°C to 50°C / (-22°F to 122°F)
Warranty
2-year warranty


Overview

  • IP66
  • IK07
  • DMX
  • RDM
  • I
  • Meets CE safety standards, Rohs compliant

Optional Features

  • Corrosion resistant coating for product installation in coastal environment available on request
  • External Wireless Data
  • CSA certified version available on request
