Goboled 80 D

AL2502

  • Single gobo outdoor rated image projector
  • 425x164x280mm / 16.7x6.5x11"
  • Maximum creativity, dynamism and flexibility
  • Bright and accurate rendition of graphic designs, logos and pattern
  • Extreme reliability and totally noiseless operation

View finishes: Black RAL 9005
  • Black RAL 9005
  • Anthracite RAL 7016
  • Grey RAL 9006
  • White RAL 9003
  • Custom RAL available on request
Contact us  Save product
COLOUR CHANGINGTUNABLE & SOLID WHITE LIGHT
print

General Features

Projecting a bright and accurate rendition of graphic designs, logos and patterns in outdoor and indoor locations with the help of a dichroic or metal gobo, the versatile image projector GOBOLED 80 D, fitted with a single powerful LED, provides maximum creativity, dynamism and flexibility for the most demanding design and application requirements.
Colour configuration
One high brightness 6500K power LED
Optical configuration
Manual adjustment of focus and linear zoom (20°÷32°)
Max. Delivered lumen output
1621 lm max.
One dichroic filter (can be used in combination with a metal gobo)
Linear 0 to 100% electronic dimmer
Strobe facility (25 FPS max)
Input voltage
100-240VAC / 50-60 Hz
Power consumption
100W
DMX Wireless
Optional external wireless system
Ingress protection rating
IP65
Impact resistance rating
IK07
External operating limits
-20°C to 40°C / (-4°F to 104°F)
Warranty
2-year warranty


Overview

  • IP65
  • IK07
  • DMX
  • I
  • Meets CE safety standards, Rohs compliant

Optional Features

  • Corrosion resistant coating for product installation in coastal environment available on request
  • External Wireless Data
  • CSA certified version available on request
