Jupiter Dynamic White

AL5340

  • Compact and powerful surface-mount floodlight
  • 186x134x223 mm / 7.3x5.3x8.8"
  • Comprehensive selection of optical configurations
  • Polar Edition available
  • High brightness tunable white power LEDs

View finishes: Black RAL 9005
  • Black RAL 9005
  • Anthracite RAL 7016
  • Grey RAL 9006
  • White RAL 9003
  • Custom RAL available on request
Contact us  Save product
TUNABLE & SOLID WHITE LIGHT
print

General Features

With a modern, clean design for minimal impact on the urban landscape, JUPITER DW is a versatile medium-throw, exterior surface mounted floodlight, distinguished by a surprising luminous efficacy. With eight different optical configurations, JUPITER DW features unique design flexibility, a lightweight and compact body, and printed front glass with no visible screws. With an adjustable colour temperature range between 2700K and 6500K, the pure white light spectrum intensity management creates a stunning visual rendering of warm tones, natural hues and cool shades altogether. Anthracite, silver grey, black or white finishes are available as standard options. The Polar Edition, which is equipped with an integrated de-icing system with electrically heated front glass, always ensures perfect operating in even the most severe weather conditions, including heavy snow or ice formation.
Video
Colour configuration
High brightness Dynamic White LEDs with an adjustable colour temperature range between 2700K and 6500K
Optical configuration
12° SP (Spot)
15° NA (Narrow)
25° ME (Medium)
47° WI (Wide)
61° EW (Extra wide)
14°x39° EL (Elliptical)
22°x37° WL (Elliptical wide)
19° (5° incline)x37° WW (Wall wash)
Input voltage
120-277VAC / 50-60Hz
Power consumption
0.18A@230V / 38W max.
Ingress protection rating
IP67
Impact resistance rating
IK07
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Optional feature
The fixture is also available in Class II, on request
Polar Edition
Available on request.
Warranty
5-year warranty
Accessories
Optional optical distribution and mounting accessories available for the utmost design flexibility

Light Beam Effects

  • Spot
  • Narrow
  • Medium
  • Wide
  • Extra Wide
  • Elliptical
  • Elliptical wide
  • Wall wash


Overview

  • IP67
  • IK07
  • DMX
  • RDM
  • DALI
  • I
  • Meets CE safety standards, Rohs compliant

Optional Features

  • Corrosion resistant coating for product installation in coastal environment available on request
  • Optional Polar
  • External Wireless Data
  • ETL Listed
  • Class II

Downloads
