Jupiter MC RGBW


  • Max. delivered lm output: 1643 lm / 43 lm/W
  • Size: (HxWxD) 223x186x134 mm / 8.8x7.3x5.3”
  • Control system: DMX-RDM, DALI DT8, DALI, remote wireless data
  • Compact floodlight fitted with multichip LEDs

View finishes: Black RAL 9005
  • Black RAL 9005
  • Anthracite RAL 7016
  • Grey RAL 9006
  • White RAL 9003
  • Custom RAL available on request
View LED colour configuration: RGB+W 4000K
  • RGB+W 4000K
  • RGB+W 3000K
Contact us  Save product

General Features

JUPITER MC is an alternative multichip LED configuration with distinctive aesthetics, using quad-color LEDs for superior color mixing directly at the lens. The efficient combination of powerful RGB+W 4000K or 3000K multichip LEDs and unparalleled optical lenses, deliver seamless light distribution and smooth colour transitioning. Featuring a lightweight and compact body, printed front glass and no visible screws, JUPITER MC RGBW offers anthracite, silver grey, black or white finishes standard options. The Polar Edition is equipped with an integrated de-icing system with electrically heated glass for comfortable operation in the most severe weather conditions. Accessories such as visor and snoot further increase this product high versatility.
Colour configuration
High brightness RGB+W 4000K or 3000K multichip LEDs
Optical configuration
9° SP (Spot)
13° NA (Narrow)
23° ME (Medium)
50° WI (Wide)
Max. Delivered lumen output
1643 lm
Max. lumen/Watt
43 lm/W
Input voltage
120-277VAC / 50-60Hz
Power consumption
0.18A@230V / 38W max.
Ingress protection rating
Impact resistance rating
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Optional feature
The fixture is also available in Class II, on request
Polar Edition
Available on request.
5-year warranty
Optional optical distribution and mounting accessories available for the utmost design flexibility

Light Beam Effects

  • Spot
  • Narrow
  • Medium
  • Wide


  • IP67
  • IK07
  • DMX
  • RDM
  • DALI
  • DALI DT8
  • I
  • Meets CE safety standards, Rohs compliant
  • Made in Italy

Optional Features

  • Corrosion resistant coating for product installation in coastal environment available on request
  • Optional Polar
  • External Wireless Data
  • ETL Listed
  • Class II
