Moon Recessed Adjustable White Light

Moon Recessed Adjustable White Light


  • Max. delivered lm output: 959 lm / 120 lm/W
  • Max. size: (WxD) ø 112x95 mm / ø 4.41x3.74”
  • Control system: DALI, ON-OFF, 0-10V
  • Small in-ground LED uplighters with adjustable beam, available with stainless steel frame or full glass, in walk-over or drive-over versions

View frame type: Drive-over
  • Drive-over
  • Frame
  • All-glass
View LED colour configuration: 40 Natural White 4000K
  • 40 Natural White 4000K
  • 30 Warm White 3000K
  • 27 Warm White 2700K
Contact us  Save product

Moon Recessed Adjustable White Light

General Features

Owing to its extreme versatility, Moon Recessed Adjustable W is a perfect in-ground solution for marking out paths, walkways, and entrances, as well as for a distinctive illumination of architectural or landscape elements in solid white light. Featuring an exceptionally shallow recess depth, this version offers the possibility of tilting the beam direction of +/- 15° without opening the product. A printed graduated scale helps choose the desired inclination. The in-built aiming system prevents undesired light scattering, allowing well-balanced wall grazing effects as well a focused enhancement of specific architectural or landscape elements. To be used with a remote PSU, Moon Recessed Adjustable W is available in two walk-over configurations coming with either stainless steel frame or flush-mount full-glass for an elegant and discreet design with no visible screws. Featuring a 2000 Kg load bearing capacity, a robust drive-over version is suitable for installation in vehicular areas. All of the available versions rely on an IP68 protection degree for the utmost dependability and water resistance also in case of heavy rain.
Colour configuration
High brightness 2700K, 3000K and 4000K White or, on request, monochrome COB LEDs (mid-power LEDs in the Ultra Spot version)
Optical configuration
6° US (Ultraspot)
18° NA (Narrow)
25° ME (Medium)
35° WI (Wide)
50° EW (Extrawide)
33° (26° incline) x 81° WW (Wall Wash)
Max. Delivered lumen output
959 lm (US: 186 lm)
Max. lumen/Watt
120 lm/W (US: 69 lm/W)
Input current
250mA, US (Ultraspot) 800mA
Power consumption
US (Ultraspot) 2.7W, 8W
Ingress protection rating
IP68 (-1.5 m). NOT SUITABLE FOR UNDERWATER USE. The fixture is resistant to submersion up to a maximum depth of 1.5m underwater for up to thirty minutes.
Impact resistance rating
External operating limits
-40°C to 40°C / (-40°F to 104°F)
2-year warranty
Optional optical accessory available for the utmost design flexibility. Remote power supply unit to be ordered separately. Separate formwork to be ordered according to the version.

Light Beam Effects

  • Ultra Spot
  • Narrow
  • Medium
  • Wide
  • Extra Wide
  • Wall wash


  • IP68 (-1.5m)
  • IK10
  • DALI
  • 0-10V
  • III
  • Walk-over
  • Drive-over
  • Frame
  • All-glass
  • Meets CE safety standards, Rohs compliant

Optional Features

  • Anti-slip treatment, for a safe and comfortable use in pedestrian areas, available on request
  • ETL certified version available on request
  • Beehive filter
