Moon Recessed RGBW

AL5311

  • Max. delivered lm output: 132 lm / 29 lm/W
  • Max. size: (WxD) ø 100x65 mm / ø 3.9x2.6”
  • Control system: DMX-RDM, DALI, ON-OFF, 0-10V, remote wireless data
  • Small in-ground LED uplighters available with stainless steel frame or full glass, in walk-over or drive-over versions

View frame type: Drive-over
  • Drive-over
  • Frame
  • All-glass
View LED colour configuration: RGB+W 4000K
  • RGB+W 4000K
  • RGB+W 3000K
Contact us  Save product
COLOUR CHANGING
print

General Features

Owing to its extreme flexibility, high aesthetic impact, and minimal size, Moon Recessed RGBW is a perfect in-ground solution for marking out paths, walkways, and entrances, as well as for a distinctive illumination of architectural or landscape elements. Featuring a shallow recess depth for a hassle-free installation, it creates intense emotions through diverse decorative or functional lighting effects in every desired colour shade. The dynamic colour changing LED configuration is fitted with a professional technology for smart colour management, exceptional feature for an up-lighter of this size. To be used with a remote PSU, Moon Recessed RGBW is available in two walk-on configurations coming with either stainless steel frame or flush-mount full-glass for an elegant and discreet design with no visible screws. Featuring a 2000 Kg load bearing capacity, a robust drive-over version, fitted with a larger flange, is suitable for installation in vehicular areas. All of the available versions rely on an IP68 protection degree for the utmost dependability and water resistance also in case of heavy rain.
Colour configuration
High brightness RGB+W 4000K or 3000K multichip power LEDs
Optical configuration
13° NA (Narrow)
23° ME (Medium)
35° WI (Wide)
56° EW (Extrawide)
Max. Delivered lumen output
132 lm
Max. lumen/Watt
29 lm/W
Input voltage
24 VDC
Power consumption
4.6W max.
Ingress protection rating
IP68 (-1.5 m). NOT SUITABLE FOR UNDERWATER USE. The fixture is resistant to submersion up to a maximum depth of 1.5m underwater for up to thirty minutes.
External operating limits
-40°C to 40°C / (-40°F to 104°F)
Warranty
2-year warranty
Accessories
Optional optical accessory available for the utmost design flexibility. Remote power supply unit to be ordered separately. Separate formwork to be ordered according to the version.

Light Beam Effects

  • Narrow
  • Medium
  • Wide
  • Extra Wide


Overview

  • IP68 (-1.5m)
  • DMX
  • RDM
  • III
  • Walk-over
  • Drive-over
  • Frame
  • All-glass
  • Meets CE safety standards, Rohs compliant

Optional Features

  • Anti-slip treatment, for a safe and comfortable use in pedestrian areas, available on request
  • ETL certified version available on request
  • Beehive filter
