Half Moon spike White Light

AL5315

  • Max. delivered lm output: 273 lm / 91 lm/W
  • Size: Ø 32 55x182 mm total height (102 mm spike) / Ø 1.26 2.17x7.16" total height (4" spike)
  • Control system: DALI, ON-OFF, 0-10V
  • Extremely compact bollards specific for the enhancement of essential landscape or architectural details

View finishes: Anthracite RAL 7016
  • Anthracite RAL 7016
  • Olive Grey RAL 7002
  • Custom RAL available on request
View LED colour configuration: 40 Natural White 4000K
  • 40 Natural White 4000K
  • 30 Warm White 3000K
  • 27 Warm White 2700K
Contact us  Save product
TUNABLE & SOLID WHITE LIGHT
print

General Features

Half Moon spike W is an extremely compact LED luminaire capable of enhancing outdoor ambiances with discretion and elegance through the creation of refined accent lighting effects. Its external power supply unit allows a comfortable installation even in the least spaces and the simultaneous management of multiple units. Half Moon spike W is capable of creating intense emotions through soft effects in different shades of white, highlighting with extreme precision small exterior elements in private houses as well as plants, flowerbeds, and bushes in gardens and green areas. Available in 2 finish nuances and with three different optics, it comes with a 10 cm long spike for direct installation in the ground. Two alternative versions feature either one-tone finish or brass swivel options for the utmost design flexibility.
Colour configuration
High brightness 2700K, 3000K and 4000K White or, on request, monochrome power LEDs
Optical configuration
NA (Narrow) 12°
ME (Medium) 23°
WI (Wide) 43°
Max. Delivered lumen output
273 lm
Max. lumen/Watt
91 lm/W
Input current
900mA
Power consumption
3W
Ingress protection rating
IP67
Impact resistance rating
IK07
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Warranty
5-year warranty

Light Beam Effects

  • Narrow
  • Medium
  • Wide


Overview

  • IP67
  • IK07
  • III
  • Meets CE safety standards, Rohs compliant

Optional Features

  • Corrosion resistant coating for product installation in coastal environment available on request
  • ETL pending
