Orpheo S RGBW

AL4860 Single Emission
AL4862 Double Emission

  • LED wall-mount diffuser
  • 150x262x234 mm / 5.9x10.3x9.2"
  • Single (downwards) or double (upwards and downwards) vertical light emission
  • Integrated electronic driver
  • Premium quality high brightness RGBW power LEDs

View finishes: Black RAL 9005
  • Black RAL 9005
  • Anthracite RAL 7016
  • Grey RAL 9006
  • White RAL 9003
  • Custom RAL available on request
Contact us  Save product
COLOUR CHANGING
print

General Features

ORPHEO S RGBW is a wall-mount diffuser whose single (downwards) or double (upwards and downwards) vertical light shaft provides elegant accent or wall grazing effects. Digitally controlled RGBW LEDs configurations, combined with different optics choices, give maximum chromatic adaptability. The double light shaft version can feature independent LED and optics configurations combined with fully autonomous control of each LED cluster, enhancing absolute design flexibility. The integrated electronic driver guarantees comfortable set-up. The combination of premium class RGBW LEDs, featuring 4000K natural white, delivers the widest range of warm white shades and pastel tones assortment.
Colour configuration
High brightness RGB+W 4000K LEDs
Optical configuration
7° SP (Spot)
12° NA (Narrow)
21° ME (Medium)
43° WI (Wide)
Input voltage
100-240VAC / 50-60 Hz
Ingress protection rating
IP66
Impact resistance rating
IK10
External operating limits
-30°C to 50°C / (-22°F to 122°F)
Warranty
5-year warranty
Accessories
Unless an RDM control is used, ORPHEO S RGBW must always be purchased with one AL2660 WeeZerd 1 to set its DMX address

Light Beam Effects

  • Spot
  • Narrow
  • Medium
  • Wide


Overview

  • IP66
  • IK10
  • DMX
  • RDM
  • I
  • Meets CE safety standards, Rohs compliant

Optional Features

  • Corrosion resistant coating for product installation in coastal environment available on request
  • ETL Listed

Downloads
