Parade LB 2 Recessed W DALI - ON-OFF

Parade LB 2 Recessed W DALI - ON-OFF


  • Max. delivered lm output: 2212 lm / 111 lm/W
  • Size: 680x142x117 mm /26.8x5.6x4.6"
  • Control system: DALI, ON-OFF
  • Recessed linear module with integrated PSU specific for wall grazing effects
  • Please note that the formwork must be purchased separately.

View LED colour configuration: 40 Natural White 4000K
  • 40 Natural White 4000K
  • 30 Warm White 3000K
  • 27 Warm White 2700K
Contact us  Save product

Parade LB 2 Recessed W DALI - ON-OFF

General Features

Fitted with 12 premium quality high brightness power LEDs, PARADE LB 2 recessed features an unquestionably powerful luminous flux with real uniform distribution even on close-up installations for truly impressive wall grazing enhancement especially on large-scale architectural elements. This IP67 rated DALI/ON-OFF fixture, equipped with integrated power supply unit, is the ideal solution for those applications which do not require RDM/DMX function. A comprehensive selection of optical configurations further enhances this in-ground linear profile versatility. The natural or warm white LEDs set-ups available provide an unprecedented astonishing white light output quality allowing a broad range of application purposes.
Colour configuration
High brightness 4000K Natural White, 3000K or 2700K Warm White or, on request, monochrome power LEDs
Optical configuration
12° SP (Spot)
15° NA (Narrow)
25° ME (Medium)
48° WI (Wide)
61° EW (Extra wide)
14°X39° EL (Elliptical)
23°x37° WL (Elliptical wide)
19° (5° incline)x38° WW (Wall wash)
Max. Delivered lumen output
2212 lm
Max. lumen/Watt
111 lm/W
Input voltage
120-277VAC / 50-60Hz
Power consumption
0.13A@230VAC / 27W max.
Ingress protection rating
Impact resistance rating
External operating limits
-20°C to 45°C / (-4°F to 113°F)
2-year warranty

Light Beam Effects

  • Spot
  • Narrow
  • Medium
  • Wide
  • Extra Wide
  • Elliptical
  • Elliptical wide
  • Wall wash


  • IP67
  • IK10
  • DALI
  • ON-OFF
  • I
  • Walk-over
  • Meets CE safety standards, Rohs compliant
  • Made in Italy

Optional Features

  • Anti-slip treatment, for a safe and comfortable use in pedestrian areas, available on request
  • ETL pending
