Parade L-1 RGBW

AL5060
AL5061 Polar Edition

  • Linear module specific for wall grazing effects
  • 318x76x70 mm / 12.5x3x2.7"
  • Comprehensive selection of optical configurations
  • Polar Edition available
  • High brightness RGB+W 4000K power LEDs

View finishes: Black RAL 9005
  • Black RAL 9005
  • Anthracite RAL 7016
  • Grey RAL 9006
  • White RAL 9003
  • Custom RAL available on request
Contact us  Save product
COLOUR CHANGING
print

General Features

Fitted with 12 premium quality high brightness power LEDs, PARADE L-1 RGBW features an unquestionably powerful luminous flux with real uniform colour coverage even on close-up installations for truly impressive wall grazing enhancement especially on large-scale architectural elements. A comprehensive selection of optical configurations and a vast choice of body finishes further enhance this linear profile tremendous flexibility and versatility. The combination of prime class RGBW LEDs, featuring 4000K natural white, delivers the largest range of warm white shades and pastel tones assortment. The Polar Edition is equipped with an integrated de-icing system with electrically heated glass, which assures a comfortable functioning even in the utmost severe cold weather conditions.
Colour configuration
High brightness RGB+W 4000K LEDs
Optical configuration
7° SP (Spot)
11° NA (Narrow)
21° ME (Medium)
43° WI (Wide)
69° EW (Extra wide)
9°X41° EL (Elliptical)
20°x38° WL (Elliptical wide)
13° (5° incline)x37° WW (Wall wash)
Input voltage
220-240VAC / 50-60Hz
Power consumption
0.1A@230V / 20W max.
Ingress protection rating
IP67
Impact resistance rating
IK09
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Polar Edition
Available on request.
Warranty
5-year warranty
Accessories
One Infrared Remote Control AL1321 must always be purchased for DMX/RDM versions, unless an RDM compatible control is used. More PARADE L-1 RGBW units can be controlled with one AL1321.  PARADE L-1 RGBW must always be purchased with fixing brackets.

Light Beam Effects

  • Spot
  • Narrow
  • Medium
  • Wide
  • Extra Wide
  • Elliptical
  • Elliptical wide
  • Wall wash


Overview

  • IP67
  • IK09
  • DMX
  • RDM
  • Self-addressing
  • I
  • Meets CE safety standards, Rohs compliant

Optional Features

  • Corrosion resistant coating for product installation in coastal environment available on request
  • Optional Polar
  • External Wireless Data
  • ETL Listed
