Fitted with 36 premium quality high brightness power LEDs, PARADE L3 RGBW features an unquestionably powerful luminous flux with real uniform colour coverage even on close-up installations for truly impressive wall grazing enhancement especially on large-scale architectural elements. Featuring one-foot-long independent pixel clusters, the alternative independent pixel version has been specifically developed to create dynamic visual concepts on large-scale architectural spaces, where video animation or graphic patterns can be displayed to generate an eye-catching lighting show. A comprehensive selection of optical configurations and a vast choice of body finishes further enhance this linear profile tremendous flexibility and versatility. The combination of prime class RGBW LEDs, featuring either 4000K natural white or 3000K warm white, delivers the largest range of warm white shades and pastel tones assortment. The Polar Edition is equipped with an integrated de-icing system with electrically heated glass, which assures a comfortable functioning even in the utmost severe cold weather conditions.
Video
Colour configuration
High brightness RGB+W 4000K or 3000K LEDs
Optical configuration
9° SP (Spot) 11° NA (Narrow) 26° ME (Medium) 43° WI (Wide) 60° EW (Extra wide) 12°x42° EL (Elliptical) 53°x14° E1 (Elliptical) 65°x20° E2 (Elliptical) 65°x40° E3 (Elliptical) 25°x45° WL (Elliptical wide) 13° (5° incline)x37° WW (Wall wash)
Max. Delivered lumen output
2538 lm
Max. lumen/Watt
44 lm/W
Input voltage
220-240VAC / 50-60Hz
Power consumption
0.26A@230V / 58W
Ingress protection rating
IP67
Impact resistance rating
IK09
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Polar Edition
Available on request.
Warranty
5-year warranty
Accessories
One Infrared Remote Control AL1321 must always be purchased for DMX/RDM and independent pixels versions, unless an RDM compatible control is used. More PARADE L-3 RGBW units can be controlled with one AL1321. PARADE L-3 RGBW must always be purchased with fixing brackets.
