Parade L-4 RGBW

AL5075
AL5076 Polar Edition

  • Linear module specific for wall grazing effects
  • 1219x76x70 mm / 48x3x2.7"
  • Comprehensive selection of optical configurations
  • Alternative independent pixel version available
  • High brightness RGB+W 4000K power LEDs

View finishes: Black RAL 9005
  • Black RAL 9005
  • Anthracite RAL 7016
  • Grey RAL 9006
  • White RAL 9003
  • Custom RAL available on request
Contact us  Save product
COLOUR CHANGING
print

General Features

Fitted with 48 premium quality high brightness power LEDs, PARADE L-4 RGBW features an unquestionably powerful luminous flux with real uniform colour coverage even on close-up installations for truly impressive wall grazing enhancement especially on large-scale architectural elements. Featuring one-foot-long independent pixel clusters, the alternative independent pixel version has been specifically developed to create dynamic visual concepts on large-scale architectural spaces, where video animation or graphic patterns can be displayed to generate an eye-catching lighting show. A comprehensive selection of optical configurations and a vast choice of body finishes further enhance this linear profile tremendous flexibility and versatility. The combination of prime class RGBW LEDs, featuring 4000K natural white, delivers the largest range of warm white shades and pastel tones assortment. The Polar Edition is equipped with an integrated de-icing system with electrically heated glass, which assures a comfortable functioning even in the utmost severe cold weather conditions.
Video
Colour configuration
High brightness RGB+W 4000K LEDs
Optical configuration
7° SP (Spot)
11° NA (Narrow)
21° ME (Medium)
43° WI (Wide)
69° EW (Extra wide)
9°X41° EL (Elliptical)
20°x38° WL (Elliptical wide)
13° (5° incline)x37° WW (Wall wash)
Input voltage
220-240VAC / 50-60Hz
Power consumption
0.35A@230V / 78W
Ingress protection rating
IP67
Impact resistance rating
IK10
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Polar Edition
Available on request.
Warranty
5-year warranty
Accessories
One Infrared Remote Control AL1321 must always be purchased for DMX/RDM and independent pixels versions, unless an RDM compatible control is used. More PARADE L-4 RGBW units can be controlled with one AL1321. PARADE L-4 RGBW must always be purchased with fixing brackets.

Light Beam Effects

  • Spot
  • Narrow
  • Medium
  • Wide
  • Extra Wide
  • Elliptical
  • Elliptical wide
  • Wall wash


Overview

  • IP67
  • IK10
  • DMX
  • RDM
  • Independent pixels
  • Self-addressing
  • I
  • Meets CE safety standards, Rohs compliant

Optional Features

  • Optional Polar
  • External Wireless Data
  • ETL Listed
