  • Max. delivered lm output: 2292 lm / 43 lm/W
  • Size: (WxD) ø 280x153 mm / ø 11x6”
  • Control system: DMX-RDM, remote wireless data
  • Drive-over multichip LED uplighter featuring shallow recessed depth
  • Please note that the formwork needs to be purchased separately

View LED colour configuration: RGB+W 4000K
  • RGB+W 4000K
  • RGB+W 3000K
Contact us  Save product

General Features

Featuring shallow recessed depth for a comfortable in-ground installation, RUBY MC R RGBW is a highly performing uplighter specifically designed for exterior recessed applications and the ideal solution for spot lighting and wall grazing effects. Based on an efficient combination of strikingly powerful multichip LEDs, which enhance seamless light distribution and smooth colour transition, the combination of premium class RGBW LEDs, featuring either 4000K natural white or 3000K warm white, delivers the widest range of warm white shades and pastel tones assortment. This compact IP67 rated light fitting features a 2000 Kg deadweight load capacity that makes it suitable for ground mounting applications even in vehicular areas. The Polar Edition features an integrated de-icing system with electrically heated glass, which assures a comfortable functioning even in the utmost severe cold weather conditions.
Colour configuration
High brightness RGB+W 4000K or 3000K multichip LEDs
Optical configuration
7° SP (Spot)
10° NA (Narrow)
25° ME (Medium)
36° WI (Wide)
Max. Delivered lumen output
2292 lm
Max. lumen/Watt
43 lm/W
Input voltage
100-277VAC / 50-60 Hz
Power consumption
0.25A@230V / 53W
Ingress protection rating
Impact resistance rating
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Polar Edition
Available on request.
2-year warranty
Unless an RDM compatible control is used, RUBY MC R RGBW must always be purchased with AL1321 Infrared Remote Control. More RUBY MC R RGBW units can be controlled with one AL1321.

Light Beam Effects

  • Spot
  • Narrow
  • Medium
  • Wide


  • IP67
  • IK09
  • DMX
  • RDM
  • I
  • Drive-over
  • Meets CE safety standards, Rohs compliant
  • Made in Italy

Optional Features

  • Anti-slip treatment, for a safe and comfortable use in pedestrian areas, available on request
  • Optional Polar
  • ETL certified version available on request
