  • Comprehensive optical configurations selection
  • Ø 280/263 mm x 155/150 mm / Ø 11/10.3x6/5.9"
  • Shallow recessed depth
  • 2000 Kg deadweight load capacity
  • Premium class RGB+W 4000K or 3000K LEDs
  • Please note that the formwork must be purchased separately.

Contact us  Save product

General Features

Specifically designed for exterior recessed applications, RUBY R RGBW is a highly performing LED fixture featuring shallow recessed depth for a comfortable in-ground installation. IP67 rated, RUBY R RGBW is ideal for spot lighting and wall grazing owing to the wide selection of exchangeable optics groups available, ranging from spot aperture beams to wall wash distribution. The new combination of premium class RGBW LEDs, featuring either 4000K natural white or 3000K warm white, delivers the widest range of warm white shades and pastel tones assortment. A 2000 Kg deadweight load capacity makes this compact unit suitable for ground mounting applications even in vehicular areas.
Colour configuration
High brightness RGB+W 4000K or 3000K LEDs
Optical configuration
7° Spot (SP)
11° NA (Narrow)
21° ME (Medium)
43° WI (Wide)
69° EW (Extra wide)
9°X41° EL (Elliptical)
20°x38° WL (Elliptical wide)
14° (16° incline) x 37° (Wall wash)
Max. Delivered lumen output
1581 lm (SP RN configuration)
Input voltage
100-277VAC / 50-60 Hz
Power consumption
0.17A@230VAC / 36W max.
Ingress protection rating
Impact resistance rating
External operating limits
-40°C to 50°C / (-40°F to 122°F)
2-year warranty
Unless an RDM compatible control is used, RUBY R RGBW must always be purchased with AL1321 Infrared Remote Control. More RUBY R WGBW units can be controlled with one AL1321.

Light Beam Effects

  • Spot
  • Narrow
  • Medium
  • Wide
  • Extra Wide
  • Elliptical
  • Elliptical wide
  • Wall wash


  • IP67
  • IK09
  • DMX
  • RDM
  • I
  • Drive-over
  • Meets CE safety standards, Rohs compliant

Optional Features

  • Anti-slip treatment, for a safe and comfortable use in pedestrian areas, available on request
  • ETL Listed
